Korg MS-20 Mini Analog Synthesizer
$399.00
(No reviews yet)
Write a Review
Korg MS-20 Mini Analog Synthesizer
The Korg MS-20 Mini is an 86% scale replica of the iconic 1978 MS-20 analog synthesizer. Developed under the supervision of the original engineers, it faithfully reproduces the legendary analog circuitry, aggressive self-oscillating high/low-pass filters, and flexible semi-modular patch bay while adding modern USB-MIDI and standard MIDI In connectivity.
Key Description & Architecture
- Synthesis Type: Monophonic Analog (Subtractive)
- Filters: Self-oscillating high-pass and low-pass filters featuring distinctive distortion when pushed into resonance. The Mini uses the gritty first-generation filter design.
- External Signal Processor (ESP): Allows external audio sources (like guitars or vocals) to drive the pitch or volume to control the synth or route audio through the filters.
- Patch Bay: Flexible 1/8" jack patching system for radical routing and experimental sound design.
Technical Specifications
- Keyboard: 37 mini-keys (3 octaves, velocity and aftertouch unsupported)
- Oscillators (VCOs):
- VCO 1: Sawtooth, square, triangle, white noise
- VCO 2: Sawtooth, square, pulse, ring modulator
- Inputs & Outputs:
- Audio Out: 1 x 1/8" mono line output
- Headphone Out: 1 x 1/8" stereo mini phone jack
- Audio In: 1 x 1/8" signal input for ESP
- MIDI: 5-pin DIN MIDI In and USB-MIDI Type B (Note messages only, channel 1)
